Mikrofon Preamplifier
Mic Gain Range: 58dB
Line Gain Range: 58dB (-10dB pad)
Phantom Power: 48v +/-4v @ 10mA/Channel
Mic EIN: <-128dBu
CMRR: >85dB @ 1kHz
Maximum Input Level: +16dBu
Input Impedance (Mic): >3kΩ Balanced
Input Impedance (Line): >10kΩ Balanced
Frequency Response: +/-0.5dB 10Hz to 40kHz
Crosstalk: <-105dBu @ 1kHz & 10kHz
THD+N @ 0dBu (1kHz): <0.0015%
SNR: 100dB
XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)
D.I
D.I Gain Range: 58 dB
Maximum Input Level: +10dBu
Input Impedance: 1MegΩ Unbalanced
Frequency Response: +/-0.5dB 10Hz to 20kHz
THD+N @ 0dBu (1kHz): <0.3%
SNR: 100dB
1/4” Jack: TIP (Hot) & SLEEVE (Shield)
ADC girişler
Digital Reference Level: 0dBFS = +8dBu
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: -105dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz): <0.001%
Dynamic Range: 113dB A-weighted
DAC çıkışlar
Maximum Output Level: +11dBu
Digital Reference Level: 0dBFS = +11dBu
Output Impedance: <100Ω Balanced
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: <-110dBu @ 1kHz
THD+N @ -1dBFS (1kHz): <0.0015%
Dynamic Range: 113dB A-weighted
1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)
Kulaklık çıkışı
Output Impedance: <50Ω
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: -110dBu @ 1kHz
THD+N @ -1dBFS (1kHz): <0.0015%
Dynamic Range: 113dB A-weighted
Max Level Into 30ohms: +0.5dBu, 0.0025% THD+N, 1.16Vpk Power: 45mW
Max Level Into 60ohms: +4.22dBu, 0.0015% THD+N, 1.78Vpk Power: 52mW
Max Level Into 600ohms: +10.1dBu, 0.0018% THD+N, 3.52Vpk Power: 20mW
1/4” Jack: TIP (Left), RING (Right) & SLEEVE (Shield)
DSP Mixer Roundtrip Latency:
(Giriş ve Çıkış)
44.1 kHz / 0.594ms
48.0 kHz / 0.552ms
88.2 kHz / 0.302ms
96.0 kHz / 0.281ms
DAW Playback Latency
@ 32 Sample Buffer for Software Instrument Playback
44.1 kHz / ~2.5ms
96.0 kHz / ~2ms
DAW Roundtrip Software Monitoring Latency
@ 32 Sample Buffer (giriş ve çıkış)
44.1 kHz / 5ms
96.0 kHz / 4.1ms
Gecikme/Latency - Arabellek ve CPU yükü, işletim sistemi ve diğer sürücülerin performansı gibi birçok faktöre bağlı olduğundan, gecikme/latency - performansı değişebilir.
USB 2.0 High Speed
Giş kanal sayısı: 2 Analog
Çıkış kanal sayısı: 2 Digital
Konnektör: USB Type-C
Dahili kablolar: 1m USB 2.0 Type-C'den USB Type-A'ya
Ağırlık & Boyutlar
Ağırlık: 360g
Paket ağırlığı: 600g
Boyutlar: 140mm (w) x 67mm (h) x 67mm (d)
Paket boyutu: 172mm (w) x 88mm (h) x 97.5mm (d)
